Enclosure Air Conditioner

Enclosure air conditioners control temperature and humidity inside electrical cabinets and control enclosures used in industrial systems, such as machinery panels, outdoor communication cabinets and base stations, where sensitive electronic components operate. Through a refrigeration cooling cycle, heat is removed from inside the enclosure and released to the outside environment. Besides maintaining stable internal conditions, preventing overheating, and extending the service life of electronic components, enclosure cooling systems also protect them from dust and corrosive gases.

Contact Us
Specification Sheet
Specifications
Model AC-01 AC-02 AC-03 AC-04 AC-06 AC-08 AC-12 AC-24
Cooling Capacity W 290 580 870 1160 1740 2325 3485 6975
Kcal/h 250 500 750 1000 1500 2000 3000 6000
Power Supply Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz Single Phase AC 220V 50/60Hz
Rated Power (W) 450 500 600 750 1100 1100 1300 4000
Rated Current (A) 1.5 2.3 2.6 3.3 4 4.7 5.6 18
Operating Temperature (℃) 20-50 20-50 20-50 20-50 20-50 20-50 20-50℃ 20-50
Ambient Temperature (℃) 5-45 5-45 5-45 5-45 5-45 5-45 5-45℃ 5-45
Noise Level ≤65 dB ≤65 dB ≤68 dB ≤68 dB ≤68 dB ≤68 dB ≤68 dB ≤68 dB
Protection Rating IP44 IP44 IP44 IP44 IP44 IP44 IP44 IP44
Cutout Dimensions (mm) 253×293 318×345 318×345 360×370 360×370 360×370 390×498.5 620×990
Dimensions (mm) 290×195×555 365×235×655 365×235×655 412×265×775 287×418×733 287×418×733 468×287×883 688×480×1177
Weight (kg) 18.5 29 32 42 44 44 52.5 125
Features
  • Enclosure air conditioners use eco-friendly refrigerants, high-efficiency compressors and evaporative cooling technology to reduce energy consumption, limit ozone impact and support green manufacturing requirements.
  • They maintain precise temperature control inside electrical enclosures with an accuracy of ±1°C and can optionally include dehumidification and humidification functions to keep stable temperature and humidity conditions, which helps extend equipment service life.
  • These cooling systems can be customized with an intelligent control system that enables process monitoring, zone-based control and automatic adjustment, with optional IoT connectivity for remote operation and maintenance management.
With over a decade of dedication to industrial process cooling and thermal management for industrial equipment, we have established us as a reliable manufacturer of industrial process chillers, enclosure air conditioners, air-air heat exchangers and oil mist collectors. We understand that every production process has different thermal requirements and operational demands. From CNC machining and semiconductors to laser processing and electronics manufacturing, we deliver the industrial cooling solutions designed to keep your production and operation running with temperature consistency and thermal stability. With all industrial chillers and industrial equipment thermal control systems certified by CE and ISO, we are committed to assisting you in optimizing production efficiency, minimizing downtime and reducing operational costs.
